Access Control

Q3 header
  • TYPE OF SCANNER: Optical fingerprint scanner
  • • Fingerprint Templates:3,000
  • • Cards:10000
  • • Transactions:100,000
  • ENROLLMENT & VERIFICATION
  • • Methods: Fingerprint (1:1, 1:N), card or password
  • • Recommended Fingerprint per user ID: 2
  • • Fingerprint Placement: Any angle
  • • Verification Time (sec): less than 1 second
  • CARD TECHNOLOGY
  • • RFID: 64-bit, 125kHz: Yes
  • • MIFARE: MFIS50/S70, 13.56MHz: Made to order
  • COMMUNICATIONS
  • • Method: TCP/IP, RS232, RS485, Flash disk
  • • Baud rates: 9600, 19200, 38400, 57600, 115200
  • • Wiegand: 26-bit input / output

Access control limits access to a system, physical or virtual resources. There are four main elements that make up an access control system, which are credentials, readers, locking devices and controllers/panels.
Our Access control product comes with an advanced door security software. Both software applications generate a various 16 useful reports and seamlessly integrate with the hardware that is being used by thousands around the world

Features

  • TIME ATTENDANCE
  • • To collect all clocking data automatically & systematically
  • • Fast & effective data management by powerful software
  • • Verification combination with fingerprint, password and RFID card
  • • “Touch & Go” concept for effective operation

  • ACCESS CONTROL
  • • Eliminating unauthorized access
  • • Constant monitoring of staff movement
  • • Extra security with combination of fingerprint, password and RFID card
  • • Easy integration with different types of door lock system
  • • 50 time zones with 5 groups to control staff accessibility
  • • Trigger alarm for tamper switch released, forced access, duress case & external siren
  • • Supports antipassback feature
Layout Plan
SURFACE FINISHING Acrylonitrile Butadiene Styrene (ABS)
TYPE OF SCANNER Optical
PRODUCT DIMENSION (L X W X H), mm 162 x 42 x 110
STORAGE
• Fingerprint templates 3000
• Transaction 50000
ENROLLMENT & VERIFICATION
• Methods Fingerprint (1:1, 1:N), Password & Card
• Recommended fingerprint per user ID 2
• Fingerprint placement Any angle
• Verification time (sec) <1
• FAR (%) < 0.0001
• FRR (%) < 1
CARD TECHNOLOGY
• RFID: 64-bit, 125kHz Yes
• MIFARE: MFIS50/S70, 13.56MHz Made to order
• HID: HID 1325, 26-bit, 125kHz Made to order
COMMUNICATIONS
• Method TCP/IP, RS232, RS485, USB flash disk
• Baud rates 9600, 19200, 38400, 57600, 115200
OPERATING ENVIRONMENT
• Temperature (°C) 0 ~ 45
• Humidity (%) 20 ~ 80
• Power input DC12V 3A
TIME ATTENDANCE
• Work codes Yes
MULTIMEDIA
• Voice Yes
ACCESS CONTROL
• EM lock driving output DC12V 3A
• Alarm output NO/NC
• Antipassback N/A
VOICE / DISPLAY LANGUAGE (TERMINAL) English (Standard) / Other languages are available upon request.
SOFTWARE LANGUAGE English, Arabic, Indonesian, Spanish, Chinese, Thai, Vietnamese,
French, Persian, Italian, Russian, Malay, Portuguese, German
